Scanner Type

ADF (Automatic Document Feeder) / Manual Feed, Duplex

Scanning Speed^*1 (A4 Portrait)
(Color^*2/Grayscale^*2/Monochrome^*3)

Simplex

50 ppm (200/300 dpi)

Duplex

100 ipm (200/300 dpi)

Image Sensor Type

CIS x 2 (front x 1, back x 1)

Light Source

RGB LED x 2 (front x 1, back x 1)

Optical Resolution

600 dpi

Output Resolution^*4
(Color / Grayscale / Monochrome)

50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver)^*5

Output Format

Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit

Background Colors

White / Black (selectable)

Document Size

Maximum^*6

215.9 x 355.6 mm (8.5 x 14 in.)

Minimum

48 x 50 mm (1.9 x 2 in.)

Long Page Scanning^*7

6,096 mm (240 in.)

Paper Weight (Thickness)

Paper

20 to 465 g/m² (5.3 to 124 lb)^*8

Booklet

Less than 7 mm (0.276 in.)^*9

Plastic Card

1.4 mm (0.055 in.) or less^*10

ADF Capacity^*11*12

100 sheets (A4 80 g/m² or Letter 20 lb)

Expected Daily Volume^*13

8,000 sheets

Multifeed Detection

Overlap detection (Ultrasonic sensor), Length detection

Paper Protection

Image monitoring

Interface

USB

USB 3.2 Gen1x1 / USB 2.0 / USB 1.1

Ethernet

10BASE-T, 100BASE-TX, 1000BASE-T

Power Requirements

AC 100V - 240V 50/60 Hz

Power Consumption

Operating Mode

21 W or less / 17 W (Eco mode)

Sleep Mode

LAN: 2.0 W or less
USB: 1.4 W or less

Auto Standby (Off) Mode

0.2 W or less

Operating Environment

Temperature

5 to 35 °C (41 to 95 °F)

Relative Humidity

15 to 80% (Non-condensing)

Environmental Compliance

ENERGY STAR®, RoHS

Dimensions (W x D x H)^*14

300 x 170 x 163 mm (11.8 x 6.7 x 6.4 in.)

Weight

4 kg (8.8 lb)

Supported Operating System

Windows® 11^*15, Windows® 10^*15, Windows® 8.1, Windows® 7, Windows Server® 2022, Windows Server® 2019, Windows Server® 2016, Windows Server® 2012 R2, Windows Server® 2012, Windows Server® 2008 R2, macOS^*16, Linux (Ubuntu)^*16

Included Software / Drivers

PaperStream IP Driver (TWAIN/TWAIN x64/ISIS), WIA Driver^*17, Image Scanner Driver for macOS (ICA)^*17*18, Image Scanner Driver for Linux (SANE)^*17*18, PaperStream Capture, PaperStream ClickScan^*18, PaperStream NX Manager, Software Operation Panel, Error Recovery Guide, ABBYY FineReader for ScanSnap™^*18, Scanner Central Admin

Image Processing Functions

Multi image output, Automatic color detection, Blank page detection, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Dither, De-Screen, Emphasis, Dropout color (None/Red/Green/Blue/White/Saturation/Custom), sRGB output, Hole punch removal, Index tab cropping, Split image, De-Skew, Edge filler, Vertical streaks reduction, Background pattern removal, Cropping, Static threshold

Included Items

ADF paper chute, AC cable, AC adapter, USB cable, Setup DVD-ROM
